Retractable Flap Barrier Gate Stainless Steel Pedestrian Turnstiles Wing Barrier

Shenzhen Wejoin Mechanical & Electrical Co.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Retractable Flap Barrier Gate Stainless Steel Pedestrian Turnstiles Wing Barrier

Brand Name : WEJOIN

Model Number : WJTY202

Certification : ISO

Place of Origin : China

MOQ : 1set

Price : Negotiation

Payment Terms : T/T, Western Union

Supply Ability : 3000 SETS/ Month

Delivery Time : 3-7 working DAYS

Packaging Details : WOODEN BOX

Close Opening Time : 0.5s

Housing Finished : Stainless Steel

Flap Speed : Adjustable

Flap Material : Oganic Glass

Infrared Photocell : Yes

Customized products : Yes

Safety : Yes

Contact Now



Organic Speed Gate Retractable Flap Barrier Gate Stainless Steel Pedestrian Turnstiles





Company introduction:



Shenzhen Wejoin Machinery & Electrical Technology Co. Ltd, was established in March 2004. it is the first high-tech enterprise engaged in research and development, manufacture and sales of intelligent access control products. Wejoin was awarded Brand Business Enterprise of Guangdong province, enterprise with independent innovation product of Shenzhen city, Longgang district first 100 Excellent Performance training pilot enterprise. As one of the most potential branding enterprise in Shenzhen, one of the largest manufactures in gate controlling products, barrier gates, and passageway barrier, well known manufacturer in the world, the key supplier for the access control and management. Our main product sinclude automatic barrier, passageway barrier gate operators, etc.





Feature and Function:



1. A compact electric and mechanical design with unique drive which ensure product durability and silent operation, and its self-lock mechanism can also well protect the access control security.

Retractable Flap Barrier Gate Stainless Steel Pedestrian Turnstiles Wing Barrier



2.WEJOIN flap barrier barriers have automatic detection for malfunctions, which will be convenient for customer to maintain and operate.



3.WEJOIN flap barrier barriers have input interface that are available for dry contact and switch signal connections. So that customers can integrate the flap barrier with different system, like card reader, ticket system, token system etc.



4.WEJOIN flap barrier barriers have auto delay closing function, after the flaps open if no pedestrian passes in a fixed time, the system will cancel the order and the auto-delay closing time is adjustable. The press button 1 and button 2 can adjust the delay closing time.



5.WEJOIN flap barrier barriers can be integrated with fire control device, which allow the release on emergency for security consideration.



6.WEJOIN flap barrier barriers have audible and visual alarm in case of unauthorized access, which can strengthen the entrance security.



7. Infrared photocells for safety access



8. Anti-reversing passing



9. Auto closing when power on



10. Auto open and free access when power off



11. Adjustable access directions



13. Traffic light indicating passenger access



14. Battery is needed.



Data:



                  Model

Item

WJTY201

WJTY301

WJTY311



WJTS111

Material of Housing

304 Stainless Steel



Material of Flap Door

Organic Glass, Resin, or PVC



Iron with powder

Dimension of housing

1200*270*1000

1450*315*1020

1400*305*1020



420*380*1050

Thickness of housing

1.5mm



Max Width of Passage

600

900

900



Net weight

70kg

140 kg

85 kg



45 kg

Normal Life Span

3 millions times



Communication Interface

Standard RS485(distance less than 1200 meters)



Transit speed

30-40 persons/min



Power supply

220V±10%, 110± 10%



Frequency

50/60HZ



Working voltage of motor

DC24V



Time for opening or closing

1s



Starting time after power on

3s



Input interface

Dry contact signal or +12Vor pulse signal with width more than

100ms DC12V





Transit speed

25~32 persons/min



Working temperature

-10°C~50°C



Working environment

Indoor / Outdoor (Shelter)



Relative humidity

≤95%, no condensation
